Woodward 5462-529 from SAUL ELECTRIC | In Stock
1.5462-529 Product Overview
The Woodward 5462-529 belongs to the 505/505E series digital turbine controllers. It is a microprocessor-based control module designed for single-valve steam turbines,
including single extraction/admission systems or split-range actuator configurations.
The controller features a front panel Operator Control Panel (OCP) with a two-line, 24-character display and multi-function keypad, allowing easy on-site configuration and monitoring.
contacts： Mike
+86 18350224834 （WeChat/WhatsApp）
Email：Mike18350224834@gmail.com
2. 5462-529 Technical Specifications and Parameters
| Parameter | Details |
|---|---|
| Power Supply | +24 VDC, approx. 1 A |
| I/O Outputs | Discrete Outputs: 8 Analog Outputs: 6 Actuator Outputs: 2 |
| Display / HMI | Two-line, 24-character LCD, with multi-function keypad |
| Dimensions | Approx. 14 × 11 × 4 in (35.6 × 27.9 × 10.2 cm) |
| Weight | Approx. 9.11 lbs (4.13 kg) |
| Operating Temperature | –4 to +140 °F (–20 to +60 °C) |
| Storage Temperature | –40 to +185 °F (–40 to +85 °C) |
| Humidity Standard | 95% RH at 20-55 °C for 48 hours without damage |
| Protection Class | Typically meets industrial dust and water protection standards |
| Communication Protocol | Supports Modbus, RS-232 / RS-422 serial interfaces |
3. Brand History
Woodward, Inc., founded in 1870 and headquartered in Fort Collins, Colorado, USA, is a global leader in energy control systems. The company has a long history of innovation in turbine control, engine management,
and power generation systems.
Woodward products are widely recognized for their reliability and precision in demanding industrial and power generation applications.
4. Applications in Industrial Automation
The 5462-529 plays a critical role in industrial automation and power generation environments:
- Steam Turbine Control: Manages startup, speed regulation, and extraction/admission control of steam turbines.
- Power Generation Systems: Used in power plants to regulate turbine-driven generators for stable frequency and load management.
- Compressor and Pump Drive Control: Ensures precise speed control for turbine-driven compressors and pumps.
- Process Industry Applications: Applied in chemical plants, refineries, and other industries requiring precise turbine operation.
- Safety and Protection Functions: Includes overspeed protection, critical speed avoidance, actuator travel limits, and event logging for operational safety.
The difference between PWM controller and MPPT controller
In off grid photovoltaic systems, solar charge and discharge controllers are essential for protecting batteries from overcharging
and discharging, and extending battery life. After years of development, the technology of pulse width modulation (PWM) type charging
controllers has become very mature. However, we have found that in practical cases, the power generation of photovoltaic power plants
after operation is often lower than the original design value, which not only causes system waste but also brings a lot of inconvenience to application.
How to solve this problem reasonably has brought a challenge to everyone. Some may increase power generation by designing larger
solar panels, but this result will inevitably increase system costs even more. Is there a way to increase power generation without increasing system costs?
MPPT controller is undoubtedly a good choice. The so-called MPPT (Maximum Power Point Tracking) refers to maximum power point tracking.
The maximum power point tracking controller is a device designed in the controller that can perform intelligent calculations
and implement real-time tracking to achieve real-time monitoring of the power generation voltage of the solar panel, and track
the highest voltage and current value (VI).
By outputting the highest point of electrical energy, the system charges the battery with the highest efficiency.
