Woodward 8237-2597 Price Discount | In Stock
1.8237-2597 Product Overview
The Woodward 8237-2597 belongs to the 505/505E series digital turbine controllers. It is a microprocessor-based control module designed for single-valve steam turbines,
including single extraction/admission systems or split-range actuator configurations.
The controller features a front panel Operator Control Panel (OCP) with a two-line, 24-character display and multi-function keypad, allowing easy on-site configuration and monitoring.
contacts： Mike
+86 18350224834 （WeChat/WhatsApp）
Email：Mike18350224834@gmail.com
2. 8237-2597 Technical Specifications and Parameters
| Parameter | Details |
|---|---|
| Power Supply | +24 VDC, approx. 1 A |
| I/O Outputs | Discrete Outputs: 8 Analog Outputs: 6 Actuator Outputs: 2 |
| Display / HMI | Two-line, 24-character LCD, with multi-function keypad |
| Dimensions | Approx. 14 × 11 × 4 in (35.6 × 27.9 × 10.2 cm) |
| Weight | Approx. 9.11 lbs (4.13 kg) |
| Operating Temperature | –4 to +140 °F (–20 to +60 °C) |
| Storage Temperature | –40 to +185 °F (–40 to +85 °C) |
| Humidity Standard | 95% RH at 20-55 °C for 48 hours without damage |
| Protection Class | Typically meets industrial dust and water protection standards |
| Communication Protocol | Supports Modbus, RS-232 / RS-422 serial interfaces |
3. Brand History
Woodward, Inc., founded in 1870 and headquartered in Fort Collins, Colorado, USA, is a global leader in energy control systems. The company has a long history of innovation in turbine control, engine management,
and power generation systems.
Woodward products are widely recognized for their reliability and precision in demanding industrial and power generation applications.
4. Applications in Industrial Automation
The 8237-2597 plays a critical role in industrial automation and power generation environments:
- Steam Turbine Control: Manages startup, speed regulation, and extraction/admission control of steam turbines.
- Power Generation Systems: Used in power plants to regulate turbine-driven generators for stable frequency and load management.
- Compressor and Pump Drive Control: Ensures precise speed control for turbine-driven compressors and pumps.
- Process Industry Applications: Applied in chemical plants, refineries, and other industries requiring precise turbine operation.
- Safety and Protection Functions: Includes overspeed protection, critical speed avoidance, actuator travel limits, and event logging for operational safety.
The difference between PWM controller and MPPT controller
PWM controller pulse width modulation (PWM) refers to the use of digital outputs from microprocessors to control analog circuits,
and is a method of digital encoding of analog signal levels. Controlling analog circuits digitally can significantly reduce the cost and
power consumption of the system. Many microcontrollers contain PWM controllers.
The MPPT controller can detect the power generation voltage of the solar panel in real time and track the highest voltage and current value
(VI), enabling the system to charge the battery at maximum power output. Applied in solar photovoltaic systems, coordinating the work of solar
panels, batteries, and loads is the brain of the photovoltaic system. So let”s take a look at the differences between PWM controllers and MPPT controllers.
